QCL-100 High-speed Picosecond Pulsed Laser

QCL-100 High-speed Picosecond Pulsed Laser provided ultra-short laser pulses typically of several tens of picoseconds. Applying the originally-developed narrow-pulse-shaping technique, outstanding features are obtained, including high repetition frequency, narrow pulse width, high extinction, phase randomization. QCL-100 high-speed picosecond pulsed laser with high performance and low cost is an excellent candidate for quantum secret communication, single photon detector test and other applications.

  1. High repetition rate
  2.  Ultra-narrow pulse width
  3.  The maximum extinction ratio
  4.  1 to 4 channels available, small volume
  5.  High peak power
  6.  Auxiliary synchronous output
  7.  Optional polarization maintaining fiber output
  8.  Stability
  1. Quantum key distribution (QKD)
  2.  Time-resolved fluorescence analysis
  3.  Single photon generation
  4.  The test of single photon detector
  5.  Laser radar
laser
wavelength1550nm/1310nm/
850nm
output formsSMF output, FC/APC
optical pulse output
pulse width30ps--100ps
peak power>0dBm, 5dBm (typ.)
extinction ratio>30dB
repetition frequency>1.25GHz
